Tea Cup Making Machine

Automatic Paper Cup Machine

Model DM550
Speed 50-55 Cups/Min
Cup Size 40-330 ML
Power 3.5 KW
Dimension 2800 x 1400 x 1700 mm
Weight 1600 Kg
Price ₹ 6,50,000.00

Special Features

  • Single shaft gear system
  • Oil recycling automatic system
  • Two-way paper feeding system
  • Fully automatic process: paper feeding, cup fan wall sealing, oiling, bottom punching, heating, rolling, and rimming
  • Equipped with 125 type gearbox for longer life and higher accuracy (better than standard 100 type gearbox)
more about us

Automatic Paper Cup Machine

Model DM650
Speed 60-65 Cups/Min
Cup Size 40-330 ML
Power 3.5 KW
Dimension 2800 x 1400 x 1700 mm
Weight 2000 Kg
Price ₹ 7,50,000.00

Special Features

  • Single shaft gear system
  • Oil recycling automatic system
  • Two-way paper feeding system
  • Fully automatic process: paper feeding, cup fan wall sealing, oiling, bottom punching, heating, rolling, rimming, rounding and tripping
  • Equipped with 125 type gearbox for longer life and higher accuracy
  • Cup folding parts controlled by three separate larger cams
  • Each folding clip can be adjusted independently for precise operation
more about us

Automatic Paper Cup Machine

Model DM750
Speed 75-80 Cups/Min
Cup Size 40-330 ML
Power 3.5 KW
Dimension 2800 x 1400 x 1700 mm
Weight 2200 Kg
Price ₹ 8,00,000.00

Special Features

  • Improved model based on normal chain driving type
  • Open cam system instead of gear system (no gearbox)
  • Automatic lubrication system
  • Adopted open cam mechanism for smoother and stable operation
  • Sealed by copper heating rod for better sealing
  • Reduced leakage problems with improved heating system
more about us

High Speed Paper Cup Machine

Model DM1000 H
Speed 85-90 Cups/Min
Cup Size 40-330 ML
Power 4.5 KW
Dimension 2300 x 1200 x 1800 mm
Weight 2500 Kg

Special Features

  • Advanced cam and gear transmission system
  • All parts manufactured with standardized production process
  • Automatic lubrication system for continuous high-speed operation
  • High precision components with low noise performance
  • Optimized internal machine structure
  • Enhanced stability and reliable core mechanism
more about us

High Speed Paper Cup Machine

Model DM1000 HSD
Speed 100-105 Cups/Min
Cup Size 40-330 ML
Power 6 KW
Dimension 2200 x 1200 x 1900 mm
Weight 2700 Kg
Price ₹ 9,50,000.00

Special Features

  • Automatic closed lubrication system for long continuous high-speed operation
  • Open cam and gear transmission system
  • Stable machine operation even under high speed
  • Imported heating system ensures cups remain leak-free at high speed
more about us
